Manufacturing Specifications and Features:

• Manufacturing Standard –IBR,ASME 16.34,API 602.
• Testing standards: API 598, ASME 16.34
• Pressure/Class Range: #150 to # 2500
• Complete hard-faced area for improved life of seat and disc.
• Sizes available: 1”, 1-1/2” and 2”
• End connections -Socket-End, Buttweld-End, Flanged End.
• MOC available: A105, F22,WCB, WC6, CF8, CF8M, Special MOC on request.
• Operation – Manual, Motorized and Lever Operated.
• Available in Single Stage and Multi-Stage Plug for High Pressure Regulation.
